Kufotokozera mwatsatanetsatane ndondomeko yogwirira ntchito, magawo a chitsanzo, ndi mapangidwe amkati ama valve pneumatic solenoid
Monga chigawo chapakati pamakina a pneumatic, mfundo yogwira ntchito yamavavu a pneumatic solenoid yagona pakugwiritsa ntchito mwanzeru mphamvu yamagetsi yamagetsi. Vavu ya solenoid ikapatsidwa mphamvu, koyiloyo imapanga mphamvu ya maginito, kukopa chitsulo chachitsulo kuti chisunthe, motero mpweya woponderezedwa ukhoza kudutsa pakati pa valve ndikulowa mu valve solenoid. Vavu ya solenoid ikatha-mphamvu, mphamvu ya maginito imazimiririka nthawi yomweyo, ndipo kasupe amatseka mwamphamvu pakati, kuletsa mpweya kudutsa.
Valavu ya pneumatic solenoid imapangidwa makamaka ndi ma electromagnet ndi thupi la valve. Gawo la electromagnet lili ndi pakati pachitsulo, koyilo, ndi bulaketi yokonza pakati pachitsulo. Pamene koyiloyo ipatsidwa mphamvu, mphamvu ya maginito imapangidwa, chitsulo chachitsulo chimakopeka, ndipo panthawi imodzimodziyo, mpweya woponderezedwa pamtunda wolowera mpweya ukhoza kulowa bwino mu valve solenoid. Mphamvu ikatha, mphamvu ya maginito imatha, ndipo kuthamanga kwa kasupe kumatseka mwamphamvu pakati pa valve, kulepheretsa mpweya kudutsa.
Kuphatikiza apo, valavu ya pneumatic solenoid imakhalanso ndi mphete zosindikizira ndi ma gaskets, omwe amapangidwa kuti atsimikizire kuti ntchito yosindikiza imagwira ntchito pakati pa pakati pa valve ndi mpando wa valve. Zidazi zimayenera kukhala ndi kugunda kocheperako komanso kusamva bwino kwambiri kuti zitsimikizire kuti palibe kuvala kapena kupindika pakagwiritsidwe ntchito kwa nthawi yayitali{1}}.
Pomaliza, ma valve a pneumatic solenoid amayang'anira mwanzeru njira yolowera mpweya woponderezedwa kudzera mumphamvu yamagetsi, ndipo ali ndi zabwino zambiri monga mawonekedwe ophatikizika, kukula kochepa, kulemera kopepuka, kugwira ntchito movutikira, komanso kukonza kosavuta. Zimagwira ntchito yofunika kwambiri pamakina a mpweya ndipo zimagwiritsidwa ntchito kwambiri-kuletsa, kubweza, ndi kuwongolera gasi ndi zina zotero.
| 1️⃣Matchulidwe a Khodi | 7V: 5-njira 2-malo Pneumatic Solenoid Vavu | |||||||||
| 2️⃣Series Kodi | 05:05000 Series | 1:100 Series | 2:200 Series | |||||||
| 3️⃣Mode yowongolera zamagetsi | 10: Dual-position Single Electronic Control 20: Dual-position Dual-electronic Control |
|||||||||
| 30C: Atatu-maudindo a Dual Electronic Control Center Otsekedwa Mtundu 30E: Three-position Dual-electronically Controlled Mid-Exhaust Type 30P: Atatu-maudindo a Dual Electronic Control Median Pressure Type |
||||||||||
| 4️⃣Mtundu wa kulumikizana | Chopanda kanthu: Chitoliro cha Ulusi J: Quick{0}lumikizeni Connector Pipe |
|||||||||
| 5️⃣Dimeter yolumikizira mapaipi | Chitoliro cha Threaded | M5:M5 | 06: PT1/8 | 08: PT1/4 | ||||||
| Mwamsanga{{0}lumikizani Connector Pipe | 04: Φ 4 mm | 06: Φ 6 mm / 08: Ф 8 mm | 08: Ф 8 mm / 10: Φ 10 mm | |||||||
| 6️⃣Standard Voltage | A: AC220V B:DC24V C:AC110V F:DC12V | |||||||||
| 7️⃣Utali Waya Waya | 050:0.5m 200:2.0m | |||||||||
| 8️⃣Mano a Mawonekedwe Code | Palibe Code yotere | Chopanda kanthu: PT Dzino G: G Mano T: Mano a NPT | ||||||||
Anthu awiri okhala ndi malumikizano asanu
Mapangidwe a "two-position five-way" a valavu ya pneumatic solenoid ndi amodzi mwa mapangidwe ake apadera. Kapangidwe kameneka kakutanthauza kuti valavu ya solenoid ili ndi malo awiri ogwirira ntchito ndi njira zisanu, zomwe ndi mpweya wolowera, mpweya, doko P, doko A, ndi Port B. Kupyolera mukukonzekera mwanzeru ndi kuwongolera kolondola, dongosololi limathandizira ma valve solenoid kuti azitha kugwira ntchito monga gasi {4}kuzimitsa, kubweza, ndi kuwongolera, potero kukwaniritsa zofuna zosiyanasiyana.
Anthu awiri okhala ndi malumikizano asanu
"Maudindo awiri" apa akunena za kusintha kwa valve solenoid, ndiko kuti, valve solenoid ili ndi zigawo ziwiri. "5-way" ikuwonetsa kuchuluka kwa mawonekedwe akunja a valavu ya solenoid, kuphatikiza polowera mpweya, potulutsa mpweya, ndi doko lotulutsa mpweya, lomwe lili ndi njira zisanu. M’fanizoli, matchanelowa amalembedwa motsatira A, B, R, S, ndi T.
Anthu awiri okhala ndi malumikizano asanu
"Maudindo awiri" pano akutanthauza zigawo ziwiri zomwe valavu ya solenoid imakhala nayo panthawi yosinthira, yomwe nthawi zambiri imakhala yotseguka komanso yotsekedwa. "5-way" ikuwonetsa kuti valavu ya solenoid iyi ili ndi njira zisanu zakunja, kuphatikizapo mpweya umodzi, mpweya umodzi, ndipo mwina madoko awiri otulutsa mpweya. Makanemawa amalembedwa momveka bwino ngati A, B, R, S, ndi T, motsatana, pachithunzichi.
Pakati pawo, P imayimira gwero la mpweya wonse, pomwe A ndi B amalumikizidwa ndi masilindala. Pamene kulibe magetsi, P ndi B, komanso A ndi R, amalumikizidwa. Pamene valve solenoid ipatsidwa mphamvu, Njira idzapangidwa pakati pa P ndi A, ndipo nthawi yomweyo, B ndi S zidzalumikizidwa.
Pamene valavu ya solenoid ilibe mphamvu, P ndi B, komanso A ndi R, amalankhulana. Komabe, pamene valve solenoid ikugwiritsidwa ntchito, ndimeyi idzapangidwa pakati pa P ndi A, ndipo nthawi yomweyo, B ndi S zidzalumikizidwa.
Pamwambapa ndikufotokozera mwatsatanetsatane mfundo yogwirira ntchito, magawo achitsanzo, ndi mawonekedwe amkati a mavavu a pneumatic solenoid. Kuti mudziwe zambiri zokhudzana ndi izi, pitanihttps://www.joosungauto.com/.
