Kufotokozera Zamalonda

Ma valavu a manja a 4H opangidwa ndi pneumatic amapangidwa kuti azipereka chiwongolero chowongolera komanso chodalirika cha kayendetsedwe ka mpweya m'mafakitale osiyanasiyana opanga makina. Zopezeka m'njira zonse za 3/2 ndi 5/2 njira, mavavuwa amayendetsedwa ndi zotengera zamanja kapena zogwirira zozungulira, zomwe zimathandiza kusinthana mwachangu komanso moyenera popanda kufunikira kwamagetsi kapena ma siginecha oyendetsa ndege. Kamangidwe kake kolimba komanso kugwira ntchito kwake kosavuta kumawapangitsa kukhala abwino kukonzanso, kutseka kwadzidzidzi{7}}, ndi kutulutsa ntchito pamanja pamakina a mpweya. Monga katswiri wothandizira pneumatic ku China, timapereka ma valavu apamanja a 4H okhala ndi mitengo yampikisano komanso kupezeka kosasunthika kuti zithandizire zosowa zanu zopanga ndi zida padziko lonse lapansi.

Momwe Mungayitanitsa4H Series Pneumatic Hand Valve
4H 2 30C 08 □
① ② ③ ④ ⑤
①Model	②Kodi	③Mtundu wa vavu	④Kukula kwadoko	⑤ Mtundu wa ulusi
4H:Kubwerera pamanja 4HA:Kubwerera kwa Spring	2:200 Series	10:5/2 Njira 30C: 5/3 Way chatsekedwa pakati 30E: 5/3 Way exhaust center	06:1/8" 08:1/4"	Zopanda kanthu: PT G:G T: NPT
	3:300 Series		08:1/4" 10:3/8"

Fikirani lero kuti mumve zambiri, makatilogu azinthu, ndi mitengo yabwino kwambiri pa 4H mndandanda wamavavu am'manja a pneumatic kuti mupititse patsogolo kudalirika kwamakina anu odzichitira.

4H Series Pneumatic Hand Valve Technical Parameters

4H mndandanda Pneumatic Hand ValveZofunika Kwambiri
Chitsanzo	210-06	230-06	210-08	230-08	310-08	330-08	310-10	330-10
Madzi	Mpweya (wosefedwa ndi 40μm fyuluta chinthu)
Kuchita	Manual control Direct acting type)
Kukula kwadoko[Zindikirani1]	n=Kutuluka {{0}Kutopetsa=1/8		n=Kutuluka=1/4"; Exhaust=1/8"		ln=Kutuluka =Exhaust=1/4"		n=Kutuluka=3/8"; Mpweya =1/4"
Kukula kwa Orifice (Cv) [Zindikirani 3]	4H210-08:17.0mm²(Cv=1.0) 4H230C-08:13.6mm²(Cv=0.8)				4H310-10:28.0mm²(Cv=1.65) 4H330C-10:21.3mm²(Cv=1.25)
Mtundu wa vavu	5/2 njira	5/3 njira	5/2 njira	5/3 njira	5/2 njira	5/3 njira	5/2 njira	5/3 njira
Mafuta [Note2]	Osafunikira
Kupanikizika kosiyanasiyana	0~1.0MPa(0~145psi)
Umboni wokakamiza	1.5MPa (215psi)
Kutentha	-20-70 digiri
Thupi lakuthupi	Aluminiyamu alloy
Njira yogwiritsira ntchito	± 15 digiri	± 8.5 digiri	± 15 digiri	± 8.5 digiri	± 18 digiri	± 10 digiri	± 18 digiri	± 10 digiri
